LM79CCVF

Microprocessor System Hardware Monitor, 5V, 1mA, QFP, LM79CCVF

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.60~2.60 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.60~2.60

PartNumber:: LM79CCVF

Brand:: National Semiconductor - NS | Pack: QFP | D/C: 01+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Jemery's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-06-24

From Other Seller

Part Number:LM79CCVF
US $1.60 - 2.60
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
AT24C02BN-SH-T

US $0.08 - 0.15 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LM79CCVF is a Microprocessor System Hardware Monitor. In a PC, the device can be used to monitor power supply voltages, temperatures, and fan speeds. Actual values for these inputs can be read at any time, and programmable WATCHDOG limits in the LM79CCVF activate a fully programmable and maskable interrupt system with two outputs. It has an on-chip temperature sensor, 5 positive analog inputs, two inverting inputs (for monitoring negative voltages), and an 8-bit ADC. The applications of the LM79CCVF include: System Hardware Monitoring for Servers and PCs, Office Electronics, Electronic Test Equipment and Instrumentation.

Parametrics

LM79CCVF absolute maximum ratings: (1)Positive Supply Voltage (VCC): 6.5V; (2)Voltage on Any Input or Output Pin: -0.3V to (VCC+0.3V); (3)Ground Difference (GNDD–GNDA): ±300 mV; (4)Input Current at any Pin: ±5 mA; (5)Package Input Current: ±20 mA; (6)Maximum Junction Temperature(TJ max): 150℃; (7)ESD Susceptibility Human Body Model: 2000V, Machine Model: 175V; (8)Storage Temperature: -65℃ to +150℃.

Features

LM79CCVF features: (1)Temperature sensing; (2)5 positive voltage inputs; (3)2 op amps for negative voltage monitoring; (4)3 fan speed monitoring inputs; (5)Input for additional temperature sensors; (6)Chassis Intrusion Detector input; (7)WATCHDOG comparison of all monitored values; (8)POST code storage RAM; (9)ISA and I2C Serial Bus interfaces.
