HD64F2398F20V

microcomputer, QFP, –0.3 to +7.0 V, Reprogramming capability, flash memory

Rated 5 Rating 5 | reviews | Write a review

Price:: US $14.96~31.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $14.96~31.50

PartNumber:: HD64F2398F20V

Brand:: Renesas Technology Corp - Renesas | Pack: QFP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Jemery's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-12-13

From Other Seller

Part Number:HD64F2398F20V
US $14.96 - 31.50
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The HD64F2398F20V is a microcomputer (MCU: microcomputer unit). It builts around the H8S/2000 CPU, employing Renesas proprietary architecture, and equipped with peripheral functions on-chip. The HD64F2398F20V CPU has an internal 32-bit architecture, is provided with sixteen 16-bit general registers and a concise, optimized instruction set designed for high-speed operation, and can address a 16-Mbyte linear address space. The instruction set is upward-compatible with H8/300 and H8/300H CPU instructions at the object-code level, facilitating migration from the HD64F2398F20V.

Parametrics

HD64F2398F20V absolute maximum ratings: (1)Power supply voltage, VCC: –0.3 to +7.0 V; (2)Input voltage (except port 4), Vin: –0.3 to + VCC +0.3 V; (3)Input voltage (port 4), Vin: –0.3 to AVCC +0.3 V; (4)Reference voltage, Vref: –0.3 to AVCC +0.3 V; (5)Analog power supply voltage, AVCC: –0.3 to +7.0 V; (6)Analog input voltage, VAN: –0.3 to AVCC +0.3 V; (7)Operating temperature, Topr: Regular specifications: –20 to +75℃; Wide-range specifications: –40 to +85℃; (8)Storage temperature, Tstg: –55 to +125℃.

Features

HD64F2398F20V features: (1)Reprogramming capability Description amended; (2)Depending on the product, the maximum number of times the flash memory can be reprogrammed is either 100 or 1,000.; (3)Reprogrammable up to 100 times: HD64F2398TE, HD64F2398F; (4)Reprogrammable up to 1,000 times: HD64F2398TET, HD64F2398FT.
