HD64F2111BVTE10CV

microcomputer, QFP, –0.3 to +7.0 V, High-speed, Host interface, Clock pulse generator

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.86~5.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $2.86~5.00

PartNumber:: HD64F2111BVTE10CV

Brand:: Renesas Technology Corp - Renesas | Pack: QFP | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Jemery's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-03

From Other Seller

Part Number:HD64F2111BVTE10CV
US $2.86 - 5.00
SIL9030CTU

US $2.50 - 5.10 / Piece
(0) Remove
SIL9185ACTU

US $2.30 - 5.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The HD64F2111BVTE10CV is a microcomputer (MCU) made up of the H8S/2000 CPU employing Renesas Technology’s original architecture as its core, and the peripheral functions required to configure a system. The HD64F2111BVTE10CV CPU has an internal 32-bit configuration, sixteen 16-bit general registers, and a simple and optimized instruction set for high-speed operation. The H8S/2000 CPU can handle a 16-Mbyte linear address space.

Parametrics

HD64F2111BVTE10CV absolute maximum ratings: (1)Power supply voltage, VCC, VCL: –0.3 to +4.3 V; (2)I/O buffer power supply voltage, VCCB: –0.3 to +7.0 V; (3)Input voltage (except ports 7, A, P97, P86, P52, P42, and port G) , Vin: –0.3 to VCC +0.3 V; (4)Input Voltage (port A), Vin: –0.3 to VCCB +0.3 V; (5)Input voltage (P97, P86, P52, P42 and port G), Vin: –0.3 to +7.0 V; (6)Input voltage (port 7), Vin: –0.3 to AVCC + 0.3 V; (7)Reference supply voltage, AVref: –0.3 to AVCC + 0.3 V; (8)Analog power supply voltage, AVCC: –0.3 to +4.3 V; (9)Analog input voltage, VAN: –0.3 to AVCC +0.3 V; (10)Operating temperature, Topr: –20 to +75℃; (11)Operating temperature (flash memory programming/erasing), Topr: –20 to +75℃; (12)Storage temperature, Tstg:–55 to +125℃.

Features

HD64F2111BVTE10CV features: (1)High-speed H8S/2000 central processing unit with an internal 16-bit architecture Upward-compatible with H8/300 and H8/300H CPUs on an object level Sixteen 16-bit general registers 65 basic instructions; (2)Various peripheral functions; (3)8-bit PWM timer (PWM); (4)16-bit free-running timer (FRT); (5)8-bit timer (TMR); (6)Watchdog timer (WDT); (7)Asynchronous or clocked synchronous serial communication interface (SCI); (8)I2C bus interface (IIC); (9)Keyboard buffer controller; (10)Host interface (LPC); (11)10-bit A/D converter; (12)Clock pulse generator; (13)On-chip memory.
