TMS320C6414TGLZ

DSP, BGA, -0.5 V to 1.5 V, Highest-Performance, 8-Bit Overflow Protection

Rated 5 Rating 5 | reviews | Write a review

Price:: US $60.00~74.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $60.00~74.00

PartNumber:: TMS320C6414TGLZ

Brand:: Texas Instruments - TI | Pack: BGA | D/C: 08+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Jemery's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-04-06

From Other Seller

Part Number:TMS320C6414TGLZ
US $60.00 - 74.00
ECA1HHG220

US $2.00 - 10.00 / Piece
(0) Remove
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The TMS320C6414TGLZ is a DSP. It is the highest-performance fixed-point DSP generation in the DSP platform. The TMS320C6414TGLZ device is based on the second-generation high-performance very-long-instruction-word (VLIW) architecture developed by Texas Instruments (TI), making it an excellent choice for wireless infrastructure applications. The TMS320C6414TGLZ is a code-compatible member of the C600 DSP platform.

Parametrics

TMS320C6414TGLZ absolute maximum ratings: (1)Supply voltage ranges: CVDD: -0.5 V to 1.5 V; (2)DVDD: -0.5 V to 4.4 V ; (3)Input voltage ranges: (except PCI), VI: -0.5 V to 4.4 V; (4)(PCI), VIP: -0.5 V to DVDD + 0.5 V; (5)Output voltage ranges: (except PCI), VO: -0.5 V to 4.4 V; (6)(PCI), VOP [C6415T and C6416T only]: -0.5 V to DVDD + 0.5 V; (7)Operating case temperature ranges, TC: (default): 0 to 90℃; (8)Storage temperature range, Tstg: -65 to 150℃.

Features

TMS320C6414TGLZ features: (1)Highest-Performance Fixed-Point DSPs; (2)Two External Memory Interfaces; (3)Three Multichannel Buffered Serial Ports; (4)Three 32-Bit General-Purpose Timers; (5)Sixteen General-Purpose I/O (GPIO) Pins; (6)Flexible PLL Clock Generator; (7)Byte-Addressable (8-/16-/32-/64-Bit Data); (8)8-Bit Overflow Protection; (9)Bit-Field Extract, Set, Clear; (10)Normalization, Saturation, Bit-Counting; (11)VelociTI.2 Increased Orthogonality.
