Product Summary
The LT1761ES5-3.3 is a micropower, low noise, low dropout regulator. With an external 0.01mF bypass capacitor, output noise drops to 20mVRMS over a 10Hz to 100kHz bandwidth. Designed for use in battery-powered systems, the low 20mA quiescent current makes the LT1761ES5-3.3 an ideal choice. In shutdown, quiescent current drops to less than 0.1mA. The LT1761ES5-3.3 is capable of operating over an input voltage from 1.8V to 20V, and can supply 100mA of output current with a dropout voltage of 300mV. Quiescent current is well controlled, not rising in dropout as it does with many other regulators.
Parametrics
LT1761ES5-3.3 absolute maximum ratings: (1)IN Pin Voltage: ±20V; (2)OUT Pin Voltage: ±20V; (3)Input to Output Differential Voltage: ±20V; (4)ADJ Pin Voltage: ±7V; (5)BYP Pin Voltage: ±0.6V; (6)SHDN Pin Voltage: ±20V; (7)Output Short-Circut Duration: Indefinite; (8)Operating Junction Temperature Range: –40℃ to 125℃; (9)Storage Temperature Range: –65℃ to 150℃; (10)Lead Temperature (Soldering, 10 sec): 300℃.
Features
LT1761ES5-3.3 features: (1)Tiny 5-Lead SOT-23 Package; (2)Low Noise: 20mVRMS (10Hz to 100kHz); (3)Low Quiescent Current: 20mA; (4)Wide Input Voltage Range: 1.8V to 20V; (5)Output Current: 100mA; (6)Very Low Shutdown Current: < 0.1mA; (7)Low Dropout Voltage: 300mV at 100mA; (8)Fixed Output Voltages: 1.5V, 1.8V, 2V, 2.5V, 2.8V,3V, 3.3V, 5V; (9)Adjustable Output from 1.22V to 20V; (10)Stable with 1mF Output Capacitor; (11)Stable with Aluminum, Tantalum or Ceramic Capacitors; (12)Reverse Battery Protected; (13)No Reverse Current; (14)No Protection Diodes Needed; (15)Overcurrent and Overtemperature Protected.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LT1761ES5-3.3#TR |
|
IC REG LDO 3.3V .1A TSOT23-5 |
Data Sheet |
|
|
||||||||||
|
LT1761ES5-3.3#TRM |
|
IC REG LDO 3.3V .1A TSOT23-5 |
Data Sheet |
Negotiable |
|
||||||||||
|
LT1761ES5-3.3#TRMPBF |
|
IC REG LDO 3.3V .1A TSOT23-5 |
Data Sheet |
|
|
||||||||||
|
LT1761ES5-3.3#TRPBF |
|
IC REG LDO 3.3V .1A TSOT23-5 |
Data Sheet |
|
|
||||||||||
